RFI/EMI FILTERS

PCB MOUNT SINGLE PHASE

Product Code	FIF 310-3	FIF 310-6	FIF 310-10	FIF 310-15
Rated Amp.	3 AMP.	6 AMP.	10 AMP.	15 AMP.
Rated Voltage	250 VAC P-N,440 VAC	250 VAC P-N,440 VAC	250 VAC P-N,440 VAC	250 VAC P-N,440 VAC
	P-P at 50 Hz	P-P at 50 Hz	P-P at 50 Hz	P-P at 50 Hz
H.V Test for 30 Sec.	2.0 KVAC	2.0 KVAC	2.0 KVAC	2.0 KVAC
Leakage Current	2 x 0.3mA	2 x 0.3mA	2 x 0.3mA	2 x 0.3mA
Temparature rise	45° To 50°c	45° To 50°c	45° To 50°c	45° To 50°c
Insulation
Resistance	>300M ohm	>300M ohm	>300M ohm	>300M ohm
At 500 V.D.C.

Product Code	FIF 311-3	FIF 311-6	FIF 311-10	FIF 311-15
Rated Amp.	3 AMP.	6 AMP.	10 AMP.	15 AMP.
Rated Voltage	250 VAC P-N,440 VAC	250 VAC P-N,440 VAC	250 VAC P-N,440 VAC	250 VAC P-N,440 VAC
	P-P at 50 Hz	P-P at 50 Hz	P-P at 50 Hz	P-P at 50 Hz
H.V Test for 30 Sec.	2.0 KVAC	2.0 KVAC	2.0 KVAC	2.0 KVAC
Leakage Current	2 x 0.3mA	2 x 0.3mA	2 x 0.3mA	2 x 0.3mA
Temparature rise	45° To 50°c	45° To 50°c	45° To 50°c	45° To 50°c
Insulation
Resistance	>300M ohm	>300M ohm	>300M ohm	>300M ohm
At 500 V.D.C.
